Muffler (Adly ATV Q280)
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
Exhaust Pipe Ass'Y
18300-225-000
|
|||
| 2 |
Exhaust Pipe Of Front Section
18311-225-00A
|
|||
| 3 |
Silencer Muffler
18321-225-000
|
|||
| 4 |
Ex.Pipe Spring W/Rvbber
18307-225-000
|
|||
| 5 |
Muffler Shroud
18318-225-000
|
|||
| 6 |
Hex Flange Bolt, 6*10
96000-06010-08B
|
$0.74 | ||
| 7 |
Exhaust Pipe Gasket, 31.5*39*T3.5
18291-225-000
|
$4.69 | ||
| 8 |
Hex Flange Bolt, M6*20
96000-06020-10C
|
$1.84 | ||
| 9 |
Spring Clamp, 16mm
94513-16000
|
$2.01 | ||
| 10 |
Hex Flange Nut With Serration, 8mm
94050-08000C
|
$0.84 | ||
| 11 |
A.I.S Valve
17410-225-000
|
|||
| 12 |
A.I.S Hose, 70mm
17412-225-000
|
|||
| 13 |
Spring Clamp, 18mm
94513-18000
|
$3.35 | ||
| 14 |
Hose, L=60
94400-1218230
|
|||
| 15 |
Tube, 4.8*8*300
94400-0408300
|
$3.91 | ||
| 16 |
Spring Clamp
94513-08000
|
$1.26 | ||
| 17 |
Anti-Vibration Rubber, 8*27.5
18305-179-000
|
$4.02 | ||
| 18 |
Fuel Tube, 4.8*8
94400-0408200
|
|||
| 19 |
3-Way Connector
16139-120-000
|
$4.11 | ||
| 20 |
Hose, 4.8*8*150
94400-0408150
|
$5.86 |
